D

A
T
A

Passenger

1 person

L*W*H

3750*1500*2200 mm

Working Range

60 km

Max Speed

30 km/h

Min Steering radius

3.2 m

Climbing ability

15%

Charging period

6--8hour

Dustbin capacity

2.6CBM（2.2x1.4x1.35）m

E

L
E
C
T
R
I
c

Motor

72V 3000W DC MOTOR

Controller

72V 3000W Controller

Battery

72V140Lead acid Battery

Charger

Smart charger

Light&signal

Integrate assemble lamp, LED direction lamp, further and close light, revising warner, instrument, rain sweeper, warning light

C

H
A
S
S
I
S

chassis

4pcs of crossed bridges are welding by No.8 international channel steel

Suspension

Front suspension：screw rolling hydraulic spring shock absorber,
Rear suspension：heavy duty main and vice steel spring

axle

Rear axle：30mm thickness semi-suspension high, lower norty vibrator gear box

Braking system

Petal braking: 220mm hydraulic drum braking disc,
Handle brake: mechanism braking

B

O
D
y

Cab.

Moulding steel cab, tempered glasses, leather pedal pad,

painting

The body adopts 160℃ high temperature coating paint, frame and lifting system are 200℃ powder painting

hooper

It used 1.5mm thickness good quality carbon steel sealed welding, side plate is mold,Equipped with hydraulic struts to open, a side door is provided on one side of the barrel turning device, and the box cover is made of 1.0mm steel plate. The opening method of the upper cover is the one-side upper opening on one side of the barrel turning device. The front and rear gantry frames of the car box adopt a U-shaped design without breakpoints.

feature：

1. The parts are cut by CNC to ensure accuracy.

2. 2. The body adopts 3D CNC welding to ensure consistency.

3. 3. Parts spraying process. 4. Silent hydraulic system to control working noise.
