specification

L×W×H（mm）

3550X1420X1650

Cargo box size(mm)

1660X1440X290

wheel base (mm）

2320

Thread Front（mm）

1150

Thread Rear（mm）

1200

Passenger

2

Performance

Max Speed（km/h）

45

Maximum gradeability

20%

Min turning diameter（m）

≤9

Maximum turning angle

36.3(outer wheel）/42(inner wheel）

Departure angle（°）

≥38

Approach angle（°）

≥35

Ground clearance（mm)

≥150

Body Structure

Body of Cabin

sheet metal

Cargo box

Triple door bed

Battery / Motor

Battery capacity (V/Ah）

72V ， 100Ah

Working Range(km)

80-200

Battery Type

60V or 72V lead acid battery or lithium battery

Charger

portable

Charging time(h)

5~10

Motor type

60V 3KW AC Motor, 72V 4KW or 5KW AC motor is optional

Chassis / Brake

Drive type

RWD

Front Suspension

double wishbone coil spring independent suspension

Rear suspension

parallel leaf spring type(5pcs）

Drive axle speed Ratio

Unitary 10.401

Brake front

Disc

Brake rear

Drum

Wheel

12X4B（steel wheel 4X114.3）

Tire

165 R13LT

Steering type

gears chains

Power steering

○ not available

Configuration

Hood

Support pole

Door Lock

Manual

windows

Manual

Seats

Driver co-dirver seperate adjustable

Sun visor

Driver●/Co-diver ●

AC

○ not availabe

reading light

on the sun visor

Instrument type

LCD Digital Instrument

Headlamp

bulb

Rearlamp

bulb

Safty belt three point

Driver●/Co-driver●

front storage box

● （small）
