Carriage size(mm)

1630*1340*300

Wheel base(mm)

2300

Wheel tread(mm)

1195/1190

Max speed(km/h)

40

Min steering radius(m)

≤9

Max climbing ability（full）

20%

Working Range(km)

80-100

Motor

2*72V 4KW AC Motor,

Min Ground Clearance(mm)

≥150

Loading Capacity(kg)

500

ELECT

Battery

72V lead acid battery or lithium battery

Charger

Build-in smart car charger

Charging time(h)

5-10

Controller

Imported in-power controller

Driven Method

AWD

Braking Method

Front Drum Rear Drum

Body Structure

Intelligent loading body

POWER

Curb Weight(kg)

550(Without battery)

Tyre

155-70R12 tubeless tyre

Steering system

Gear chain

Model number

TK06-6/02
