Size

3475*1375*1550

Carriage size

1620*1245*300

Max speed

45km/h

Min steering radius

≤5m

Max climbing ability（full）

20%

Braking Distance

≤7m

Working Range

80-200km

Motor

72V 4KW AC motor

Min Ground Clearance

150mm

Loading Capacity（kg）

800-1200kg

Wheel Tread

1170/1184mm

Wheel base

2315mm

E

L

E

C

T

Battery

72V lead-acid maintenance-free or lithium battery option

Charger

Build-in smart car charger

Controller

Imported in-power controller

Driven Method

RR

Braking Method

Front Disc Rear Drum

Body Structure

Intelligent loading body

P

O

W

E

R

Front Axle loading Cap.

800kg

Rear axle loading capacity

1200kg

Climbing Ability

20%

Tyre

155-70R12 tubeless tyre, mountain tyre is optional

Steering system

Electronic power steering

Charging time(h)

5-10h

Seat

leather+PU

Lighting configuration

LED headlights, LED tail lights, Side/Rear reflectors
