Chassis NO.

KY/HW17-1XDP2500

Size

5000*1650*2400mm

Vehicle charging input standard

AC380V, 50HZ, 45A

Battery capacity

76.8V 560AH/43KWH

Charging station

80V,16KW/3-5H full
charged

Vehicle Rate Power

28KW

Rated power / peak of driving motor

350kw/2700w

Rated power / peak of centrual brush motor

1000w/2000w

Cleaning efficiency

≧92%

centural brush width

1200mm

Max cleaning width

2500mm

Max cleaning ability

25000m2/h

Cleaning speed

3-10km/h

Max particles Dia.

60mm

power consumption

≤8KWH/H

Max loading weight

4500kg

Max speed

≦40km/h

Continuous working time

≧5h

Garbage tank capacity

4.3m3

Dust filtering method

Dry and wet separation

Water tank volume

850L+250L

Rolling water tube

15m

Min turning radius

6.5m

Gradient

35%

Fan flow & pressure

8000m3/h & 5800PA

No. of discs and brush Dia.

2 / 4pcs Dia.:400mm/ 700with pressure

High pressure water pump flow &
pressure

15L/min & 15Mpa

Unloading degree

50%

Safety and comfortable configuration

Aviation central control panel, 360 degree visual operation and omni-directional HD camera, panoramic cab and breathable fabric
shock-absorbing seat, cold and warm switchable air conditioner, USB charging interface.
